Hikvision DS-3E0105D-O-Port Fast Ethernet Plastic Switch

The Hikvision DS-3E0105D-O is a compact and affordable 5-port Fast Ethernet Plastic Switch designed for small-scale network applications. It provides reliable connectivity and high-speed performance for various network devices, including computers, printers, and network peripherals.

Key Features:

• 5 Fast Ethernet Ports: Offers 10/100 Mbps Ethernet connectivity for basic network applications.
• MDI/MDIX Support: Automatically adjusts for straight-through or crossover cables, eliminating the need for manual configuration.
• Store-and-Forward Switching: Ensures reliable data transmission by storing and forwarding packets only after they are received in full.
• MAC Address Auto-Learning: Automatically learns and stores MAC addresses of connected devices, simplifying network management.
• Compact Design: Features a small and lightweight design for easy installation in various environments.
• Flexible Mounting: Supports both desktop and wall-mounting options for convenient placement.
• Plug-and-Play Installation: Requires no configuration, making it easy to set up and use.

Applications:

• Small Office/Home Office (SOHO): Provides a basic and affordable network infrastructure for connecting computers, printers, and other devices.
• Home Networking: Creates a high-speed network for connecting smart TVs, gaming consoles, and other home devices.
• Small Business Networks: Supports basic networking needs for small businesses, such as connecting workstations and servers. DATA SHEET

Benefits:

• Cost-Effective: Offers an affordable solution for small-scale network applications.
• Easy to Use: Plug-and-play installation and simple configuration.
• Reliable Operation: Store-and-forward switching ensures data integrity.
• Flexible Deployment: Supports both desktop and wall-mounting options for convenient placement.

Purchase from LUCENT VIRTUOSO

For a convenient and hassle-free shopping experience, consider purchasing the Hikvision DS-3E0105D-O from LUCENT VIRTUOSO

General

• ShellABS
• Net Weight0.093 kg (0.205 lb)
• Dimensions (W × H × D)83.00 mm × 22.00 mm × 52.00 mm (3.27” × 0.87” × 2.05”)
• Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
• Storage Temperature–40 °C to 85 °C (–40 °F to 185 °F)
• Operating Humidity5% to 95% (no condensation)
• Relative Humidity5% to 95% (no condensation)
• Power Supply5 VDC, 0.6 A
• Installation ModeDesk-Mounted
• Max. Power Consumption3 W
• Surge Protection2 KV

Network Parameters

• Ports5 × 10/100 Mbps RJ45 port
• MAC Address Table2 K
• Switching Capacity1 Gbps
• Packet Forwarding Rate0.74 Mpps
• Internal Cache768Kbits
